UTEx-LI

mSwitch LI Platform is composed of the LI Server (LIS) and LI Gateway (GW).The LI Server is a browser/server architecture server. The carrier operators configure and manage services from the LI Server Console.As an interception device, the LI Gateway (GW) converts the IP voice signals transmitted inside the core network to ISDN User Part (ISUP)/SIP data, and transmits them to the law enforcement monitoring facility (LEMF) via the HI 3 interface through an E1 line.

  • UTEx-LI

  • GENEW

Availability:

Product Architecture


UTEx-LI



mSwitch lawful interception defines a systematic and extensible means by which network operators and law enforcement agents can interact, especially as the complexity of networks grow and scope of services increase.

Highlights

Compliant with LI specification published by standards organizations (ETSI, 3GPP, ANSI)
Support various HI (Handover Interface) defined by different national and standards organizations
Interoperable with 3rd party LI equipment

Specifications


Category
LI SERVER
LI GATEWAY
Hardware and OS platform

  • ATCA or x86 server

  • Linux OS

  • NFV based Cloud Platform

  • cPCI chassis

  • Vxworks

Reliability
1+1 High Availability
1+1 High Availability
Interface

  • Management interface: GE

  • Signaling interface:  GE

  • Management interface: FE

  • Signaling interface:  FE, E1

Protocol

  • HI1, HI2 of ETSI spec

  • SNMP

  • Telnet

  • PRI. SS7 ISUP, SIP

  • SNMP

  • RTP, RTCP

Performance

  • Max LEA supported:  30

  • Max LI targets provisioned: 12K.

Max intercepted concurrent calls supported per E1 line card:  300m

For more information, please contact the email address globalsales@genew.com.
